Synology RackStation Plus Series RS822+ Image 0

Synology RackStation Plus Series RS822+ Image 1

Synology RackStation Plus Series RS822+

৳ 198,000 ~~৳ 267,568~~

0.00 (0)

Key Features

CPU Model : AMD Ryzen V1500B

CPU Quantity : 1

CPU Core : 4

System Memory : 2 GB DDR4 ECC SODIMM

Memory Module Pre-installed : 2 GB (2 GB x 1)

50 Star Points

30 Day Return Policy
💵 Cash on Delivery available
📦 Available for immediate dispatch from our local warehouse
Delivery within 1–3 business days

Buy Now

Category: Plus Series
Brand: Synology

Specification

CPU

CPU Model

AMD Ryzen V1500B

CPU Quantity

CPU Core

CPU Architecture

64-bit

CPU Frequency

2.2 GHz

Memory

System Memory

2 GB DDR4 ECC SODIMM

Memory Module Pre-installed

2 GB (2 GB x 1)

Total Memory Slots

Maximum Memory Capacity

32 GB (16 GB x 2)

Memory Notes

Synology recommends Synology memory modules for compatibility and warranty.

Storage

Drive Bays

Max Drive Bays with Expansion

8 (RX418 x 1)

Compatible Drive Types

3.5" SATA HDD, 2.5" SATA SSD

Hot Swappable Drive

Yes

Storage Notes

Max raw capacity not limited by single volume size limit.

External Ports

RJ-45 1GbE LAN Port

USB 3.2 Gen 1 Port

Expansion Port

Expansion Port Type

eSATA

PCIe

PCIe Expansion

1 x Gen3 x8 slot (x4 link)

Appearance

Form Factor

Size (HxWxD)

44 mm x 480 mm x 492.6 mm

Weight

6.4 kg

Rack Installation Support

4-post 19" rack (RKM114 or RKS-02, sold separately)

Cooling

System Fan

40 mm x 40 mm x 3 pcs

Fan Speed Modes

Full-Speed, Cool, Quiet

Power

Power Recovery

Yes

Noise Level

27.4 dB(A)

Scheduled Power On / Off

Yes

Wake on LAN / WAN

Yes

Power Supply Unit

150 watts

Redundant Power Supply

AC Input Voltage

100 V to 240 V AC

Power Frequency

50/60 Hz, Single Phase

Power Consumption (Access)

47.69 watts

Power Consumption (HDD Hibernation)

16.7 watts

BTU (Access)

162.83 BTU/hr

BTU (HDD Hibernation)

57.02 BTU/hr

Environment

Operating Temperature

0°C to 35°C (32°F to 95°F)

Storage Temperature

-20°C to 60°C (-5°F to 140°F)

Relative Humidity

5% to 95% RH

Certification

FCC, CE, BSMI, VCCI, RCM, UKCA, EAC, CCC, KC, UL

Warranty

2 years (extendable to 3 years with EW202 or Extended Warranty Plus)

Compliance

RoHS Compliant

Yes

Package

Included Contents

Main Unit x1, Accessory Pack x1, AC Power Cord x1, Quick Installation Guide x1

Optional Accessories

DDR4 ECC SODIMM

D4ES02-4G, D4ES02-8G, D4ES01-16G

Expansion Units

RX418

Enterprise HDD

HAT5300 Series

Plus HDD

HAT3300 Series

Enterprise SSD

SAT5200 Series

M.2 SSD & 10GbE Combo Card

E10M20-T1

M.2 SSD Adapter Card

M2D20, M2D18

25GbE Network Interface Card

E25G30-F2

10GbE Network Interface Cards

E10G21-F2, E10G30-T2, E10G18-T1

Rail Kits

RKS-02 (sliding), RKM114 (mounted)

Description

Synology RackStation RS822+ Network Storage – Key Features

The Synology RS822+ is a reliable and scalable 1U rackmount NAS solution, ideal for growing businesses looking to centralize and streamline their data management. With solid performance, advanced data protection, and expansion capabilities, this 4-bay storage system meets modern office needs in Bangladesh and beyond.

Technical Specifications:

Brand / Model: Synology RackStation RS822+
Form Factor: 1U Rackmount
Processor: AMD Ryzen V1500B Quad-Core 2.2GHz
Memory: 2GB DDR4 ECC SODIMM (Expandable up to 32GB)
Drive Bays: 4 (SATA HDD/SSD, 2.5" or 3.5")
Max Capacity: Up to 108TB (with expansion)
Expansion Unit Support: 1 x RX418 (up to 8 drives total)
PCIe Expansion: 1 x Gen3 x8 slot (x4 link)
Encryption Engine: AES-NI Hardware Encryption

Connectivity:

LAN Ports: 4 x Gigabit Ethernet (supporting Link Aggregation & Failover)
USB Ports: 2 x USB 3.2 Gen 1
eSATA Ports: 1
File Protocols: SMB, AFP, NFS, FTP, WebDAV, Rsync

RAID & Storage Management:

RAID Support: SHR, Basic, JBOD, RAID 0, 1, 5, 6, 10
RAID Migration: Supported
Volume Expansion: Supported with larger drives and an expansion unit
Snapshot Support: Up to 1,024 snapshots per shared folder, 65,536 system-wide

System & Power:

System Fans: 3 x 40mm
Noise Level: 27.4 dB(A)
Power Supply: 150W AC Adapter
Power Consumption:
- Active: 47.69W
- HDD Hibernation: 16.7W
BTU/hr: 162.83 (Access), 57.02 (HDD Hibernation)

Environmental Conditions:

Operating Temp: 0°C to 35°C
Storage Temp: -20°C to 60°C
Humidity: 5% to 95% RH (non-condensing)
Certifications: FCC, CE, VCCI, BSMI, RCM, UKCA, EAC, CCC, KC, UL

Performance & Capacity:

Max Concurrent Connections:
- Up to 500 users (default)
- Up to 2,000 users (with RAM upgrade)
Suggested Max Users: 750
Suggested Concurrent Users: 150
Email Performance: Up to 1.48 million emails/day (~45GB)

Surveillance Station (IP Camera Support):

H.264:
- 720p: 40 channels / 1200 FPS
- 1080p: 40 channels / 800 FPS
- 5MP: 28 channels / 280 FPS
- 4K: 17 channels / 170 FPS
H.265:
- 1080p: 40 channels / 1200 FPS
- 5MP: 40 channels / 480 FPS
- 4K: 20 channels / 200 FPS

The Synology RS822+ is an excellent solution for medium-sized businesses in Bangladesh that require dependable data protection, virtualization support, and surveillance capabilities — all in a compact and efficient 1U rackmount form factor.
